Application
It is applicable to the pharmaceutical industry, such as tablets, capsules, pills etc.
Product features
1. Processing speed can reach about 15000 pellets per minute (Depend on product's size)
2. It can handle a variety of categories of drugs, in order to save space, it take a more compact frame design
3. The food grade PVC material is used in the automatic sorting device;
4. The detection sensitivity is higher than the industry standard, the highest can be detected is 0.3mm metal ball;
5. The sensitivity can be adjusted according to the characteristics of the product, and the number of detection and elimination can be recorded in real time; Manual clear record
6. All stainless steel structure, waterproof, anti vibration, strong adaptability to the environment and temperature changes, easy to clean;
7. Modular component replacement, it’s easy to maintain
8. Multi language function selection (Chinese, English, Japanese, etc., other languages can be customized according to demand);
Specification parameters
| Item | parameter |
| Adjustable angle | 30˚ ~ 40˚ |
| Input port size | 200mm * 100mm |
| Pipe diameter | Ф40mm |
| Sensitivity (without product) | FeΦ：0.3mm |
| Non-FeΦ：0.5mm | |
| SUSΦ：0.5mm | |
| Power supply | Single phase 220V 50/60Hz. |
| Material | SUS 304 |
Notes:The sensitivity in the table is the test block falling freely through the detection of the pipeline, the actual detection sensitivity may be different according the characteristics of the product or the working environment,it should be based on the actual detection sensitivity;
